Raptor Wear Parts – Premium Mining & Heavy‑Duty Wear Solutions | TOSOG
Durable Wear Parts for Mining, Construction & Processing Operations
At TOSOG, we proudly supply Raptor Wear Parts, delivering industry-leading wear protection engineered to maximize equipment uptime, minimize maintenance costs, and significantly extend the service life of your machinery – even in the harshest and most abrasive environments. Trusted across mining, quarrying, power generation, and material handling industries, Raptor provides a full suite of high-performance wear components, including crusher liners, conveyor wear plates, G.E.T. (Ground Engaging Tools), and custom-engineered solutions.
By partnering with TOSOG, customers gain access not only to premium Raptor products but also to our local expertise, technical support, and tailored solutions, ensuring your equipment operates at peak efficiency with minimal downtime. Whether you are managing a single machine or an entire fleet, TOSOG and Raptor Wear Parts deliver the durability, reliability, and performance your operations demand.
Why Choose Raptor Wear Parts?
Raptor products are designed and engineered to maximize equipment availability and increase productivity – helping operators reduce cost per ton and boost operational efficiency.
✔ Built for Severe Wear Conditions – Engineered alloys and overlay technologies ensure superior wear resistance
✔ Custom & Standard Solutions – From engineered wear plates to custom MAO parts
✔ Global Support & Engineering Expertise – In‑house design, laser scanning and overlay services
✔ Fast Turnaround with High Quality Control – Short lead times with premium material selection
Raptor Wear Parts Product Highlights
Defender® LWP – Laminated Wear Parts
Raptor’s Defender® LWP series includes weld‑on, bolt‑on, and magnetic wear parts with a 725 BHN/63 Rc hardness backing plate for extraordinary abrasion resistance. Ideal for crushers, chutes, bins, and conveyor points of wear.
Predator® G.E.T. – Made As Ordered Wear Parts
Custom Ground Engaging Tools (G.E.T.) tailored to your equipment and application needs – available with robotic ARM, ProARM™, ARMPlus™ or PTA‑applied tungsten carbide overlay for maximum life and penetration.
RaptorPlate® High‑Chrome Wear Plate
High‑chrome carbide overlay plates deliver outstanding abrasion resistance in the harshest mining and material handling environments where wear is extreme.
HarderPlate® Premium Steel Wear Plate
Quench and tempered steel wear plates offered in 400 BHN and 500 BHN deliver excellent performance in impact‑dominated applications, often paired with RaptorPlate® for optimized life.
MagnaWear® Magnetically Attached Wear Parts
Quick‑fix magnetic wear components – such as MagnaButtons™, MagnaBolts™, and MagnaBlocks™ – extend service life until scheduled maintenance without welding downtime.
Rambo™ Tungsten Carbide SideBars
Robotically applied tungsten carbide SideBars protect structural components on draglines, loaders, and heavy equipment – reducing wear and weight while improving service life.
Complete Wear Solutions for Heavy Machines
Raptor supplies wear parts and engineered components for:
-
Draglines & Shovels – Chains, links, pins, bushings and bucket components
-
ERS & HMS Shovels – LatchBars, Dutchman inserts, undercarriage parts
-
Mineral Processing – Crusher liners, table segments, chutes, hoppers
-
Custom Buckets & Dippers – Engineered to spec for large excavators
-
Laser Scanning & Fitment Services – Precision fit kits for complex assemblies
Technology & Engineering Advantage
Raptor integrates advanced technologies such as robotic overlay systems and laser scanning – ensuring precision fit, enhanced material performance, and measurable improvements in wear life.
Industries Served
Raptor Wear Parts serve a wide range of sectors:
✔ Mining & Quarrying
✔ Construction & Dredging
✔ Power Generation Plants
✔ Mineral & Material Processing
✔ Heavy Industrial Material Handling
Partner with TOSOG for Raptor Wear Parts Solutions
Through TOSOG, you can access the complete Raptor range with expert consultation, tailored solutions, and local support. Whether you’re replacing crusher liners, upgrading G.E.T. systems, or improving wear life across your fleet, we deliver quality wear components engineered to last.
🔹 Contact us today for a quote
🔹 Customized wear solutions tailored to your operation
🔹 Expert technical support & installation guidance
Raptor Wear Parts by TOSOG
Superior Wear Protection for Maximum Equipment Performance!
ROLL BARS
PN |
Category |
Description |
Matric:
|
Weight in kg |
| WP007 | Roll Bar | Roll Bar – 1.25″ Diameter x 9.0″ Length – Raptor | 32 x 229 x 19 | 1,62 |
| WP008 | Roll Bar | Roll Bar – 1.50″ Diameter x 9.0″ Length – Raptor | 40 x 229 x 30 | 2,16 |
| WP015 | Roll Bar | Roll Bar – 1.50″ Diameter x 18.0″ Length – Raptor | 40 x 457 x 30 | 4,33 |
| WP016 | Roll Bar | Roll Bar – 2.00″ Diameter x 12.0″ Length – Raptor | 51 x 305 x 38 | 5,17 |
| WP009 | Roll Bar | Roll Bar – 1.25″ Diameter x 12.0″ Length – Raptor | 76 x 305 x 64 | 10,53 |
CHOCKY BARS
PN |
Category |
Description |
Matric:
|
Weight in kg |
| CB006 | Chocky Bar | Chocky Bar – 1.0″ Width x 9.5″ Length – Raptor | 25 x 25 x 241 | 1,21 |
| CB001 | Chocky Bar | Chocky Bar – 1.5″ Width x 9.5″ Length – Raptor | 40 x 25 x 241 | 1,61 |
| CB002 | Chocky Bar | Chocky Bar – 2.0″ Width x 9.5″ Length – Raptor | 50 x 25 x 241 | 2,19 |
| CB003 | Chocky Bar | Chocky Bar – 2.5″ Width x 9.5″ Length – Raptor | 65 x 25 x 241 | 2,75 |
| CB005 | Chocky Bar | Chocky Bar – 3.5″ Width x 9.5″ Length – Raptor | 90 x 25 x 241 | 3,88 |
| CB004 | Chocky Bar | Chocky Bar – 4.0″ Width x 9.5″ Length – Raptor | 100 x 25 x 241 | 4,45 |
| CB007 | Chocky Bar | Chocky Bar – 5.0″ Width x 9.5″ Length – Raptor | 130 x 25 x 241 | 5,58 |
WEAR BUTTON
PN |
Category |
Description |
Metric:
|
Weight in kg |
| WB001 | Wear Button | Wear Button – 1.5″ Diameter – Raptor | 65 x 22 | 0,49 |
| WB002 | Wear Button | Wear Button – 3.5″ Diameter – Raptor | 90 x 30 | 1,23 |
| WB003 | Wear Button | Wear Button – 4.5″ Diameter – Raptor | 115 x 33 | 2,32 |
| WB004 | Wear Button | Wear Button – 6.0″ Diameter – Raptor | 150 x 35 | 4,34 |
OCTAGON
PN |
Category |
Description |
||
| WB006 | Octagon | Octagon – 60mm Diameter – Raptor | 60 x 22 | 0,41 |
| WB007 | Octagon | Octagon – 75mm Diameter – Raptor | 75 x 27 | 0,75 |
| WB008 | Octagon | Octagon – 90mm Diameter – Raptor | 90 x 27 | 1,07 |
| WB009 | Octagon | Octagon – 115mm Diameter – Raptor | 115 32 | 2,14 |
| WB010 | Octagon | Octagon – 150mm Diameter – Raptor | 150 x 41 | 4,69 |
| WB011 | Octagon | Octagon – 4.0″ Width x 2.5″ Thick – Raptor | 97 x 63,5 | 3,9 |
SKID BLOCK
PN |
Category |
Description |
Metric:
|
Weight in kg |
| WP061 | Skid Block | Skid Block – 4.0″ Width x 6.0″ Length – Raptor | 112 x 153 x 34 | 3,91 |
| WP062 | Skid Block | Skid Block – 4.0″ Width x 8.5″ Length – Raptor | 112 x 216 x 34 | 5,42 |
| WP063 | Skid Block | Skid Block – 4.0″ Width x 12.0″ Length – Raptor M02333 | 112 x 305 x 34 | 7,29 |
HEEL SAVER
PN |
Category |
Description |
Metric:
|
Weight in kg |
| SH012 | Heel Shrouds | Raptor – Bucket Heel Saver – 30.0 lbs. – Mining Alloy | 42 x 203 x 203 | 13,6 |
| SH013 | Heel Shrouds | Raptor – Bucket Heel Saver – 56.0 lbs. – Mining Alloy | 64 x 190 x 258 | 24,4 |
| SH014 | Heel Shrouds | Raptor – Bucket Heel Saver – 89.0 lbs. – Mining Alloy | 75 x 250 x 250 | 40,8 |
| SH002 | Heel Shrouds | Raptor – Bucket Heel Saver – 105.0 lbs. – Mining Alloy | 72 x 256 x 312 | 47,6 |
| SH005 | Heel Shrouds | Raptor – Bucket Heel Saver – 166.0 lbs. – Mining Alloy | 102 x 24 x 350 | 75,3 |
| SH008 | Corner bar | Raptor – Bucket Heel Saver – 77.80 lbs. – Mining Alloy | 111 x 111 x 915 | 35,3 |
LIP SHROUD
PN |
Category |
Description |
Metric: T, W, L in mm |
Weight in kg |
| LS016 LS017 LS018 | Lip Savers Lip Savers Lip Savers | Raptor Lip Shroud – 13.7 LBS Raptor Lip Shroud – 28.55 LBS Raptor Lip Shroud – 59.0 LBS |
GRIZZLY CAP
PN |
Category |
Description |
Weight in kg |
|
| WP370 | Grizzly Cap | 150 to 137,5 x 305 x 50 | 13,94 | |
| WP371 | Grizzly Cap | 137.5 to 125 x 305 x 50 | 12,95 | |
| WP372 | Grizzly Cap | 125 to 112.5 x 305 x 50 | 11,9 | |
| WP373 | Grizzly Cap | 112.5 to 100 x 305 x 50 | 10,79 | |
| WP374 | Grizzly Cap | 100 to 87.5 x 305 x 50 | 9,34 | |
| WP375 | Grizzly Cap | 87.5 to 75 x 305 x 50 | 8,43 | |
| WP376 | Grizzly Cap | 75 to 62.5 x 305 x 50 | 7,17 | |
| WP377 | Grizzly Cap | 62.5 to 50 x 305 x 50 | 5,84 |
LARGER WEAR BLOCKS
PN |
Category |
Weight in kg |
||
| WP003 | Larger Wear Blocks | 150 x 203 x 38 | 9,15 | |
| WP004 | Larger Wear Blocks | 152 x 254 x 38 | 11,36 | |
| WP005 | Larger Wear Blocks | 51 x 178 x 44 | 3,04 | |
| WP312 | Larger Wear Blocks | 51 x 229 x 51 | 4,2 | |
| WP315 | Larger Wear Blocks | 76 x 152 x 39 | 3,66 | |
| WP316 | Larger Wear Blocks | 76 x 152 x 58 | 4,72 | |
| WP317 | Larger Wear Blocks | 110 x 210 x 90 | 15,71 | |
| WP318 | Larger Wear Blocks | 210 x 203 x 52 | 16,93 | |
| WP319 | Larger Wear Blocks | 210 x 203 x 86 | 25,84 | |
| WP320 | Larger Wear Blocks | 254 x 254 x 45 | 22,75 | |
| WP322 | Larger Wear Blocks | 300 x 300 x 40 | 27,66 | |
| WP323 | Larger Wear Blocks | 200 x 200 x 40 | 12,2 | |
| WP324 | Larger Wear Blocks | 250 x 250 x 40 | 19,13 |
HALF ARROWS
PN |
Category |
Description |
Weight in kg |
|
| HA115 | Long Half Arrows | 3/4″ T x 1 1/4″ T1 x 8.0″ W x 144.0″ L – 500 Grade | T1=32mm, T2=19mm, W1=203mm, W2=127mm, lenght = 3,660mm |
126,3 |
| HA116 | Long Half Arrows | 1 1/8″ T x 2 1/4″ T1 x 10.0″ W x 144.0″ L- 500 Grade | T1=57mm, T2=29mm, W1=254mm, W2=130mm, lenght = 3,660mm |
247,56 |
| HA117 | Long Half Arrows | 1 5/8″ T x 2 3/4″ T1 x 10.0″ W x 144.0″ L – 500 Grade | T1=68mm, T2=40mm, W1=254mm, W2=127mm, lenght = 3,660mm |
321,23 |
Request A Quote Now!
Tips for Maximizing the Life of Raptor Wear Parts
-
Regular Inspections – Schedule frequent visual inspections of wear components to detect early signs of abrasion, cracking, or misalignment. Early detection prevents costly downtime.
-
Proper Installation – Always follow manufacturer installation guidelines. TOSOG provides expert support to ensure your Raptor Wear Parts are fitted correctly for maximum performance.
-
Monitor Material Flow – Abrasive materials can wear components faster. Adjust feed rates and material distribution to reduce uneven wear on critical areas like chutes and crusher liners.
-
Rotate and Replace Strategically – Where possible, rotate wear plates and G.E.T. components to even out wear patterns, extending the overall lifespan of your parts.
-
Use Overlay Options When Needed – Tungsten carbide overlay or high-chrome options offered by Raptor can significantly increase wear life in high-impact areas.
-
Keep Components Clean – Build-up of debris can accelerate wear and reduce efficiency. Regularly clean chutes, hoppers, and other wear surfaces.
-
Partner with TOSOG Experts – Leverage TOSOG’s technical expertise to select the right Raptor Wear Parts for your specific machinery and application, ensuring optimal life and performance.
-
Track Performance Metrics – Maintain records of wear rates and replacement intervals to plan maintenance proactively, reduce downtime, and optimize cost-per-ton of operation.
-
Consider Custom Solutions – For extreme conditions, TOSOG can help you source or design custom-engineered Raptor components to withstand unique operational challenges.
-
Stay Up-to-Date on Technology – Raptor’s advanced robotic overlay and precision-engineered wear solutions evolve regularly. Work with TOSOG to access the latest innovations for maximum durability.
